Respironics Non-invasive ventilator

Respironics V60

Non-invasive ventilator

Trouver des produits similaires

Because every breath matters and each one is different, patients need a ventilator that follows their breathing pattern, whatever their acuity. The Philips Respironics V60 uses auto-adaptive technology to provide patient synchrony and therapy acceptance. Improved signal processing technology is finely tuned for both adult and pediatric patients.

Caractéristiques
Auto-Trak || Marketing leading hospital NIV

Advanced NIV with Auto-Trak

Provides auto-adaptive leak compensation, inspiratory triggering, and expiratory cycling to deliver optimal synchrony in the face of constantly changing leaks and patient demand-alleviating constant bedside supervision and manual adjustments.
Pre-defined mask settings || Efficient workflow

Pre-defined mask settings save time

The Philips Respironics V60 supports the success of NIV by increasing the speed and ease of treatment initiation. Its pre-defined settings for Philips Respironics hospital masks help you save time. You select the setting, and the V60 automatically calibrates flow characteristics for better monitoring and therapy.
CPAP with C-Flex || Excellent therapy

CPAP with C-Flex for greater patient comfort

CPAP (Continuous Positive Airway Pressure) with C-flex offers three levels of flow-based expiratory pressure relief. This option leads to improved sleep quality and patient comfort, adding greater flexibility and improved treatment acceptance.
Multiple treatment modes || Marketing leading hospital NIV

Multiple treatment modes for a wide range of patients

The Philips Respironics V60 helps you meet the needs of a broader patient population. Designed to include pediatric use and equipped with several modes, the V60 allows you to meet the specific needs of your patients.
Expansive color touchscreen || Efficient workflow

Expansive color touchscreen for easy operation

The Philips Respironics V60 has a high-resolution color touchscreen. The high level of visual detail makes operation easy and facilitates waveform interpretation.
PCV || Excellent therapy

PCV increases control

PCV can be used when greater control of the patient's breathing pattern is required.
AVAPS || Marketing leading hospital NIV

AVAPS

AVAPS (Average Volume Assured Pressure Support) maintains a target tidal volume in a pressure limited mode. It provides extra assurance similar to a volume limited mode with the safety of a pressure limited mode.
Standby mode || Efficient workflow

Standby mode supports patient/clinician interaction

Focus on your patients without being interrupted by nuisance alarms by switching the V60 to standby mode.
PPV || Excellent therapy

PPV for variable breathing patterns

PPV (Proportional Pressure Ventilation) delivers pressure and flow in proportion to the patient's effort, allowing the patient to more efficiently adjust their breathing to meet their changing requirements.
Internal 6-hour battery || Efficient workflow

Transport flexibility

Internal 6-hour battery enables intra-hospital transport
Auto-Trak Plus || Excellent therapy

Auto-Trak Plus for custom treatment criteria

Auto-Trak Plus, an option available in the S/T, PC, AVAPS, and PPV modes, is for the subset of patients who may benefit from a customized titration of triggering and cycling criteria. In certain patients with extremely weak efforts or in others with low compliance, Auto-Trak Plus lets clinicians make finely-tuned adjustments to the base Auto-Trak algorithm to achieve patient ventilator synchrony.
Data communication capabilities || Efficient workflow

Enhanced communications

Data communication capabilities support hospital connectivity
Respi-Link || Efficient workflow

Respi-Link* for efficient upgrades

Through this remote connection tool, you can perform efficient system diagnostics and easily apply upgrades via internet.
  • Auto-Trak || Marketing leading hospital NIV
  • Pre-defined mask settings || Efficient workflow
  • CPAP with C-Flex || Excellent therapy
  • Multiple treatment modes || Marketing leading hospital NIV
See all features
Auto-Trak || Marketing leading hospital NIV

Advanced NIV with Auto-Trak

Provides auto-adaptive leak compensation, inspiratory triggering, and expiratory cycling to deliver optimal synchrony in the face of constantly changing leaks and patient demand-alleviating constant bedside supervision and manual adjustments.
Pre-defined mask settings || Efficient workflow

Pre-defined mask settings save time

The Philips Respironics V60 supports the success of NIV by increasing the speed and ease of treatment initiation. Its pre-defined settings for Philips Respironics hospital masks help you save time. You select the setting, and the V60 automatically calibrates flow characteristics for better monitoring and therapy.
CPAP with C-Flex || Excellent therapy

CPAP with C-Flex for greater patient comfort

CPAP (Continuous Positive Airway Pressure) with C-flex offers three levels of flow-based expiratory pressure relief. This option leads to improved sleep quality and patient comfort, adding greater flexibility and improved treatment acceptance.
Multiple treatment modes || Marketing leading hospital NIV

Multiple treatment modes for a wide range of patients

The Philips Respironics V60 helps you meet the needs of a broader patient population. Designed to include pediatric use and equipped with several modes, the V60 allows you to meet the specific needs of your patients.
Expansive color touchscreen || Efficient workflow

Expansive color touchscreen for easy operation

The Philips Respironics V60 has a high-resolution color touchscreen. The high level of visual detail makes operation easy and facilitates waveform interpretation.
PCV || Excellent therapy

PCV increases control

PCV can be used when greater control of the patient's breathing pattern is required.
AVAPS || Marketing leading hospital NIV

AVAPS

AVAPS (Average Volume Assured Pressure Support) maintains a target tidal volume in a pressure limited mode. It provides extra assurance similar to a volume limited mode with the safety of a pressure limited mode.
Standby mode || Efficient workflow

Standby mode supports patient/clinician interaction

Focus on your patients without being interrupted by nuisance alarms by switching the V60 to standby mode.
PPV || Excellent therapy

PPV for variable breathing patterns

PPV (Proportional Pressure Ventilation) delivers pressure and flow in proportion to the patient's effort, allowing the patient to more efficiently adjust their breathing to meet their changing requirements.
Internal 6-hour battery || Efficient workflow

Transport flexibility

Internal 6-hour battery enables intra-hospital transport
Auto-Trak Plus || Excellent therapy

Auto-Trak Plus for custom treatment criteria

Auto-Trak Plus, an option available in the S/T, PC, AVAPS, and PPV modes, is for the subset of patients who may benefit from a customized titration of triggering and cycling criteria. In certain patients with extremely weak efforts or in others with low compliance, Auto-Trak Plus lets clinicians make finely-tuned adjustments to the base Auto-Trak algorithm to achieve patient ventilator synchrony.
Data communication capabilities || Efficient workflow

Enhanced communications

Data communication capabilities support hospital connectivity
Respi-Link || Efficient workflow

Respi-Link* for efficient upgrades

Through this remote connection tool, you can perform efficient system diagnostics and easily apply upgrades via internet.

Caractéristiques

General
General
Oxygen inlet pressure range
  • 276 to 600 kPa (40 to 87 psig)
Dimensions
  • 33.7 cm H x 39.4 cm W x 42.9 cm D (13.3"H x 15.5" W x 16.5" D)
Weight with optional battery
  • 10.9 kg (24 lb)
Weight without optional battery
  • 10.0 kg (22 lb)
Electrical
Electrical
AC power
  • 300 V·A
Battery operating time
  • 6 hours in normal conditions
AC voltage
  • 100 to 240 VAC
AC frequency
  • 50 to 60 Hz
Alarm adjustable range
Alarm adjustable range
LIP (low inspiratory pressure alarm)
  • OFF, 1 - 40 cm H₂O
Lo VE (low minute ventilation alarm)
  • OFF, 0.1 - 991 /min
Hi Vr (high tidal volume alarm)
  • 200 - 3,500 ml
Hi Rate (hi respiratory rate alarm)
  • 5 - 90 beats per minute
Lo Rate (low respiratory rate alarm)
  • 1 - 89 beats per minute
Lo Vr (low tidal volume alarm)
  • OFF - 1,500 ml
LIP T (low inspiratory pressure delay time)
  • 5 - 60 sec
HIP (high inspiratory pressure alarm)
  • 5 - 50 cm H₂O
Waveform window
Waveform window
Pressure waveform
  • 0 - 50 cm H₂O
Volume waveform
  • 0 - 3,500 ml BTPS
Flow waveform
  • 240-2401 /min BTPS
Patient Data
Patient Data
Patient/total leak
  • 0 to 200 l/min BTPS
Breath phase/trigger indicator
  • Spontaneous, Timed, Exhale
Respiratory Rate
  • 0 to 90 beats per minute
Tidal volume
  • 0 to 3000 ml BTPS
Minute volume
  • 0 to 99.0 l/min BTPS
Ti/Ttot
  • 0 to 91 %
Patient Trigger
  • 0 to 100 %
PIP
  • 0 to 50 cm H₂O
Patient types
Patient types
Suitability
  • Pediatric (≥ 20 kg) and Adult
Settings
Settings
Triggering and cycling
  • Auto-adaptive (Auto-Trak) or Auto-Trak Plus (optional). Trigger: normal, +1 to +7. Cycle: -2, -1, normal, +1 to +6
C-Flex
  • Off, 1 to 3
EPAP
  • 4 to 25 cm H₂O
Respiratory rate
  • 4 to 60 beats per minute
IPAP
  • 4 to 40 cm H₂O
Max P (PPV maximum pressure limit)
  • 5 to 40 cm H₂O
Max V (PPV maximum volume limit)
  • 200 to 3500 ml
Rise time
  • 1 to 5
Max E
  • 0 to 100 cm H2O/l
PPV%
  • 0 to 100 %
CPAP
  • 4 to 25 cm H₂O
Oxygen percentage
  • 21 to 100 %
Max P (AVAPS maximum IPAP)
  • 6 to 40 cm H₂O
Min P (AVAPS minimum IPAP)
  • 5 to 30 cm H₂O
Max R
  • 0 to 50 cm H2O/l/s
Ramp time
  • Off, 5 to 45 minute(s)
AVAPS target tidal volume
  • 200 to 2000 ml BTPS
Inspiratory time
  • 0.30 to 3.00 sec
General
General
Oxygen inlet pressure range
  • 276 to 600 kPa (40 to 87 psig)
Dimensions
  • 33.7 cm H x 39.4 cm W x 42.9 cm D (13.3"H x 15.5" W x 16.5" D)
Electrical
Electrical
AC power
  • 300 V·A
Battery operating time
  • 6 hours in normal conditions
See all specifications
General
General
Oxygen inlet pressure range
  • 276 to 600 kPa (40 to 87 psig)
Dimensions
  • 33.7 cm H x 39.4 cm W x 42.9 cm D (13.3"H x 15.5" W x 16.5" D)
Weight with optional battery
  • 10.9 kg (24 lb)
Weight without optional battery
  • 10.0 kg (22 lb)
Electrical
Electrical
AC power
  • 300 V·A
Battery operating time
  • 6 hours in normal conditions
AC voltage
  • 100 to 240 VAC
AC frequency
  • 50 to 60 Hz
Alarm adjustable range
Alarm adjustable range
LIP (low inspiratory pressure alarm)
  • OFF, 1 - 40 cm H₂O
Lo VE (low minute ventilation alarm)
  • OFF, 0.1 - 991 /min
Hi Vr (high tidal volume alarm)
  • 200 - 3,500 ml
Hi Rate (hi respiratory rate alarm)
  • 5 - 90 beats per minute
Lo Rate (low respiratory rate alarm)
  • 1 - 89 beats per minute
Lo Vr (low tidal volume alarm)
  • OFF - 1,500 ml
LIP T (low inspiratory pressure delay time)
  • 5 - 60 sec
HIP (high inspiratory pressure alarm)
  • 5 - 50 cm H₂O
Waveform window
Waveform window
Pressure waveform
  • 0 - 50 cm H₂O
Volume waveform
  • 0 - 3,500 ml BTPS
Flow waveform
  • 240-2401 /min BTPS
Patient Data
Patient Data
Patient/total leak
  • 0 to 200 l/min BTPS
Breath phase/trigger indicator
  • Spontaneous, Timed, Exhale
Respiratory Rate
  • 0 to 90 beats per minute
Tidal volume
  • 0 to 3000 ml BTPS
Minute volume
  • 0 to 99.0 l/min BTPS
Ti/Ttot
  • 0 to 91 %
Patient Trigger
  • 0 to 100 %
PIP
  • 0 to 50 cm H₂O
Patient types
Patient types
Suitability
  • Pediatric (≥ 20 kg) and Adult
Settings
Settings
Triggering and cycling
  • Auto-adaptive (Auto-Trak) or Auto-Trak Plus (optional). Trigger: normal, +1 to +7. Cycle: -2, -1, normal, +1 to +6
C-Flex
  • Off, 1 to 3
EPAP
  • 4 to 25 cm H₂O
Respiratory rate
  • 4 to 60 beats per minute
IPAP
  • 4 to 40 cm H₂O
Max P (PPV maximum pressure limit)
  • 5 to 40 cm H₂O
Max V (PPV maximum volume limit)
  • 200 to 3500 ml
Rise time
  • 1 to 5
Max E
  • 0 to 100 cm H2O/l
PPV%
  • 0 to 100 %
CPAP
  • 4 to 25 cm H₂O
Oxygen percentage
  • 21 to 100 %
Max P (AVAPS maximum IPAP)
  • 6 to 40 cm H₂O
Min P (AVAPS minimum IPAP)
  • 5 to 30 cm H₂O
Max R
  • 0 to 50 cm H2O/l/s
Ramp time
  • Off, 5 to 45 minute(s)
AVAPS target tidal volume
  • 200 to 2000 ml BTPS
Inspiratory time
  • 0.30 to 3.00 sec
  • *Not available in all markets
